X86平台智能工业相机（不含视觉软件，仅提供取图SDK）---AIA系列基于X86平台智能工业相机
AIA/AIAE是Viewsecctv威视电子基于X86平台的智能相机产品系列（不含视觉软件，仅提供取图SDK），像素从 30万到2000万像素。该系列不仅发热度低，集成度和性价比也非常高，相机内置标准windows、linux操作系统，应用程序可直接复制到相机内运行，可扩展鼠标、键盘、显示器，内部预留USB加密狗位置，无需外接电脑，非常适合单工位视觉监测，例如读码、测量、有无判断、定位等需求。
产品特色
1.AIA：CPU Intel Atom Z8350 (1 .44-1 .92GHZ)，2G/32G 4G/64G (内存/磁盘)
2.AIAE：CPU Intel N4120 (1.1-2.6GHZ)，4G/32G 4G/64G (内存/磁盘) 显示
3.HDMI ×1支持1920×1080分辨率、以太网1000M×1、支持GigE Vision相机
4.AIA：支持外接USB2.0 ×2端口;AIAE：支持USB2.0×1、USB3.0×1、支持触发
5.闪光灯x1、支持RS232 x1
6.M12 12芯螺纹航空接头, 支持12V/2A电源输入
7.1路输入, 2路输出接口可以设置输出延时, 无需在程序中处理
8.支持Windows 10 64bit、Ubuntu16.04 64bit系统
9.内置USB2.0接口一路, 方便拆装, 可接加密狗使用
10.集成光源控制器, 可选配LED照明组件, 支持频闪同步功能

产品型号 Model Number	分辨率 Resolution	帧率 Frame Rate	像元尺寸 Pixel Size	靶面尺寸 Target Size	位深 Bit Depth	传感器类型 Sensor Type	色彩 Colour	快门类型 Shutter Method
VCI-AIA033GC	640x480	790FPS	4.0um	1/5.6"	8Bit	CMOS	Color	Global
VCI-AIA033GM	640x480	790FPS	4.0um	1/5.6"	8Bit	CMOS	Mono	Global
VCI-AIA133GC	1280x1024	245FPS	4.0um	1/2.7"	8Bit	CMOS	Color	Global
VCI-AIA133GM	1280x1024	245FPS	4.0um	1/2.7"	8Bit	CMOS	Mono	Global
VCI-AIA134GC	1280x1024	211FPS	4.8um	1/2"	8Bit	CMOS	Color	Global
VCI-AIA134GM	1280x1024	211FPS	4.8um	1/2"	8Bit	CMOS	Mono	Global
VCI-AIA200GC	1600x1200	60FPS	4.5um	1/1.8"	10Bit	CMOS	Color	Global
VCI-AIA200GM	1600x1200	60FPS	4.5um	1/1.8"	10Bit	CMOS	Mono	Global
VCI-AIA202GC	1920x1200	165FPS	4.8um	2/3"	10Bit	CMOS	Color	Global
VCI-AIA202GM	1920x1200	165FPS	4.8um	2/3"	10Bit	CMOS	Mono	Global
VCI-AIA230GC	1920x1200	165FPS	5.86um	1/1.2"	8Bit	CMOS	Color	Global
VCI-AIA230GM	1920x1200	165FPS	5.86um	1/1.2"	8Bit	CMOS	Mono	Global
VCI-AIA231GC	1920x1200	40FPS	5.86um	1/1.2"	12Bit	CMOS	Color	Global
VCI-AIA231GM	1920x1200	40FPS	5.86um	1/1.2"	12Bit	CMOS	Mono	Global
VCI-AIA401GC	2048x2048	88FPS	5.5um	1"	8Bit	CMOS	Color	Global
VCI-AIA401GM	2048x2048	88FPS	5.5um	1"	8Bit	CMOS	Mono	Global
VCI-AIA501GC	2448x2048	40FPS	3.45um	2/3"	12Bit	CMOS	Color	Global
VCI-AIA501GM	2448x2048	40FPS	3.45um	2/3"	12Bit	CMOS	Mono	Global
VCI-AIA502C	2592x1944	59FPS	2.2um	1/2.5"	10Bit	CMOS	Color	Rolling
VCI-AIA502M	2592x1944	59FPS	2.2um	1/2.5"	10Bit	CMOS	Mono	Rolling
VCI-AIA630GC	3088x2064	60FPS	2.4um	1/1.8"	8Bit	CMOS	Color	Rolling
VCI-AIA630GM	3088x2064	60FPS	2.4um	1/1.8"	8Bit	CMOS	Mono	Rolling
VCI-AIA890GC	4096x2160	32FPS	3.45um	1"	12Bit	CMOS	Color	Global
VCI-AIA890GM	4096x2160	32FPS	3.45um	1"	12Bit	CMOS	Mono	Global
VCI-AIA1000C	3664x2748	8FPS	1.67um	1 /2.3"	12Bit	CMOS	Color	Rolling
VCI-AIA1000M	3664x2748	8FPS	1.67um	1 /2.3"	12Bit	CMOS	Mono	Rolling
VCI-AIA1201C	4000x3000	32FPS	1.85um	1 /1.7"	8Bit	CMOS	Color	Rolling
VCI-AIA1201M	4000x3000	32FPS	1.85um	1 /1.7"	8Bit	CMOS	Mono	Rolling
VCI-AIA1600C	4608x3456	12FPS	1.34um	1 /2.3"	12Bit	CMOS	Color	Rolling
VCI-AIA1600M	4608x3456	12FPS	1.34um	1 /2.3"	12Bit	CMOS	Mono	Rolling
VCI-AIA2000C	5488x3672	19.5FPS	2.4um	1"	8Bit	CMOS	Color	Rolling
VCI-AIA2000M	5488x3672	19.5FPS	2.4um	1"	8Bit	CMOS	Mono	Rolling
VCI-AIAE033GC	640x480	790FPS	4.0um	1/5.6"	8Bit	CMOS	Color	Global
VCI-AIAE033GM	640x480	790FPS	4.0um	1/5.6"	8Bit	CMOS	Mono	Global
VCI-AIAE133GC	1280x1024	245FPS	4.0um	1/2.7"	8Bit	CMOS	Color	Global
VCI-AIAE133GM	1280x1024	245FPS	4.0um	1/2.7"	8Bit	CMOS	Mono	Global
VCI-AIAE134GC	1280x1024	211FPS	4.8um	1/2"	8Bit	CMOS	Color	Global
VCI-AIAE134GM	1280x1024	211FPS	4.8um	1/2"	8Bit	CMOS	Mono	Global
VCI-AIAE200GC	1600x1200	60FPS	4.5um	1/1.8"	10Bit	CMOS	Color	Global
VCI-AIAE200GM	1600x1200	60FPS	4.5um	1/1.8"	10Bit	CMOS	Mono	Global
VCI-AIAE202GC	1920x1200	165FPS	4.8um	2/3"	10Bit	CMOS	Color	Global
VCI-AIAE202GM	1920x1200	165FPS	4.8um	2/3"	10Bit	CMOS	Mono	Global
VCI-AIAE230GC	1920x1200	165FPS	5.86um	1/1.2"	8Bit	CMOS	Color	Global
VCI-AIAE230GM	1920x1200	165FPS	5.86um	1/1.2"	8Bit	CMOS	Mono	Global
VCI-AIAE231GC	1920x1200	40FPS	5.86um	1/1.2"	12Bit	CMOS	Color	Global
VCI-AIAE231GM	1920x1200	40FPS	5.86um	1/1.2"	12Bit	CMOS	Mono	Global
VCI-AIAE401GC	2048x2048	88FPS	5.5um	1"	8Bit	CMOS	Color	Global
VCI-AIAE401GM	2048x2048	88FPS	5.5um	1"	8Bit	CMOS	Mono	Global
VCI-AIAE501C	2448x2048	40FPS	3.45um	2/3"	12Bit	CMOS	Color	Global
VCI-AIAE501M	2448x2048	40FPS	3.45um	2/3"	12Bit	CMOS	Mono	Global
VCI-AIAE502C	2592x1944	59FPS	2.2um	1/2.5"	10Bit	CMOS	Color	Rolling
VCI-AIAE502M	2592x1944	59FPS	2.2um	1/2.5"	10Bit	CMOS	Mono	Rolling
VCI-AIAE630GC	3088x2064	60FPS	2.4um	1/1.8"	8Bit	CMOS	Color	Rolling
VCI-AIAE630GM	3088x2064	60FPS	2.4um	1/1.8"	8Bit	CMOS	Mono	Rolling
VCI-AIAE890GC	4096x2160	32FPS	3.45um	1"	12Bit	CMOS	Color	Global
VCI-AIAE890GM	4096x2160	32FPS	3.45um	1"	12Bit	CMOS	Mono	Global
VCI-AIAE1000C	3664x2748	8FPS	1.67um	1 /2.3"	12Bit	CMOS	Color	Rolling
VCI-AIAE1000M	3664x2748	8FPS	1.67um	1 /2.3"	12Bit	CMOS	Mono	Rolling
VCI-AIAE1201C	4000x3000	32FPS	1.85um	1 /1.7"	8Bit	CMOS	Color	Rolling
VCI-AIAE1201M	4000x3000	32FPS	1.85um	1 /1.7"	8Bit	CMOS	Mono	Rolling
VCI-AIAE1600C	4608x3456	12FPS	1.34um	1 /2.3"	12Bit	CMOS	Color	Rolling
VCI-AIAE1600M	4608x3456	12FPS	1.34um	1 /2.3"	12Bit	CMOS	Mono	Rolling
VCI-AIAE2000C	5488x3672	19.5FPS	2.4um	1"	8Bit	CMOS	Color	Rolling
VCI-AIAE2000M	5488x3672	19.5FPS	2.4um	1"	8Bit	CMOS	Mono	Rolling
VCI-AIAI890GC	4096x2160	32FPS	3.45um	1"	12Bit	CMOS	Color	Global
VCI-AIAI890GM	4096x2160	32FPS	3.45um	1"	12Bit	CMOS	Mono	Global
