4.5mm 1/1.8" 2.0 Megapixel Lenses Machine Vision FA <-2.8% Low Distortion Industrial Face Recognition Scan Video Camera CCTV Lens
-
High resolution : 2 megapixel covering 1080P
-
Large format: 1/1.8" size covering 1/2", 1/2.5", 1/2.7" camera
-
Low distortion : <-2.8% super low distortion
-
Small size: Small size disign makes it various application
-
Application : Video converference, UAV, scanner, sports DV, machine vision.
|
Model
|
SND3225A-2ML
|
|
Resolution
|
2.0 Megapixel
|
|
Format (inch)
|
1/1.8" (Max image circle Φ9mm)
|
|
Focal Length (mm)
|
4.5mm
|
|
IR
|
IR
|
|
Aperture (Close)
|
F1.8 Fixed iris
|
|
Angle of View (°)
|
2/3"
|
|
|
1/1.8"
|
90*79*63
|
|
1/2"
|
|
|
M.O.D (m)
|
0.3m
|
|
Distortion
|
<-2.8%
|
|
Size
|
Φ26*23.81mm
|
|
BFL(mm)
|
7.0mm
|
|
CRA
|
9.0°
|
|
Relative illumination
|
>50%
|
|
T.T.L (mm)
|
30.13mm
|
|
Mount
|
M12*0.5
|
|
Weight (g)
|
15g
|
|
Marks
|
8G
|
|
