 2017 Viewsecctv HN-M12 Lens Data..pdf ç ( Download here )
CCTV Lens Features:
High resolution: 4.0 megapixel can cover 3MP,1080P, 720P Big aperture: F1.4 super star level support evening dark vision Large format: 1/2.7" can cover all 1/2.7", 1/3" Wide FOV : Wide FOV support short distance view. IR correction : 24h day & night vision Aspherical lens: Inside better element helps imaging far better. Application: Smart home, security surveilance, office, room, bank etc.
Model
| 127B614F12R-4
| Resolution
| 4.0 Megapixel
| Day/night
| IR
| Format | 1/2.7
| Focal Length (mm) | 6.0mm
| Aperture (Close)
| F1.4 Fixed iris
| Angle of View (°)
| 1/2.7
| 65*57*31
| 1/3
| | 1/4
|
| M.O.D (m)
| 0.2m
| Distortion
| -4.5%
| Size
| Φ14*17
| TTL (mm)
| 23.5
| Mount
| M12*0.5
| Structure ( Aspherical )
| 6G1P
| Weight (g)
| 10
|
( 6mm night view )
|
