Product name：117V3818DSR-12 (3.8-18mm) 1/1.7"

Product description：

1/1.7" 3.8-18mm 12 Megapixel CCTV Lens Surveillance Security Camera Safe City ITS Industrial Face Recognition IR Day Night C Mount Bank Lenses

High resolution: 12 megapixel cover 4K & 1080P
Wide focal length: Covering 3.8-18mm, 3.8-16mm, 4-16mm, 4-12mm
Big aperture: F1.5 suitable for dark vision
Large format: 1/1.8" can cover all 1/1.8",1/2",1/2.5", 1/2.7"
IR correction: 24h day & night vision
Application: All bldg., school, exit, room, metrol, highway.

Model		117V3818DSR-12
Resolution		12.0 Megapixel
IR Corrected		IR
Format (inch)		1/1.7"
Focal Length (mm)		3.8-18mm
Aperture (Close)		F1.5 DC Iris
Angle of View (°)	2/3"
	1/1.7"	*14511079*
	1/2"
M.O.D (m)		0.3m
Size		Φ51x82mm
Distortion		-28.6% ~ -2.6%
Mount		CS
Weight (g)		251

( Viewsecctv 3.8-18mm at 3.8mm Wide side,drag the picture to enlarge )

( H brand lenses edge and center not good )
