CCTV Lens Features:
High resolution: 4.0 megapixel can cover 3MP,1080P, 720P Big aperture: F1.4 super star level support evening dark vision Large format: 1/2.7" can cover all 1/2.7", 1/3" Wide FOV : Wide FOV support short distance view. IR correction : 24h day & night vision Aspherical lens: Inside better element helps imaging far better. Application: Smart home, security surveilance, office, room, bank etc.
Model
| 127B414F12R-4
| Resolution
| 4.0 Megapixel
| Day/night
| IR
| Format | 1/2.7"
| Focal Length (mm) | 4.0mm
| Aperture (Close)
| F1.4 Fixed iris
| Angle of View (°)
| 1/2.7"
| 110*97*54
| 1/3"
| 100*79*59
| 1/4"
|
| M.O.D (m)
| 0.1m
| Distortion
| -12%
| Size
| Φ14*17.8
| TTL (mm)
| 23.4
| Mount
| M12*0.5
| Structure ( Aspherical )
| 3G3P
| Weight (g)
| 10
|
( 4mm star-light night view )
( 4mm day time view cloudy )
|
