Product name:OLED Inspection Lenses 16K
Product description:



Model

SMV10016-16K

Resolution

16K

Focal Length (mm)

100mm

Max image circle

φ82

Aperture

F1.6  Manual Iris

Angle of View

26.6

Magnification

3.35×

3.5×

3.65×

Working DistanceA+B

49.7±5

48.4±5

47.3±5

Conjugate Distance

537.99±9

551.79±9

409.9±0.5

Flange Focal Distance

379.7±0.5

394.8±0.5

409.9±0.5

ENP Diameter

62.2

Distortion

0.01%

Telecentric

3°

Marks

clearance

Application

OLED Inspection
